简介
The 3842/43/44/45 are fixed frequency current mode PWM controller. They are specially designed for OFF-Line and DC to
DC converter applications with a minimal external components. Internally implemented circuits include a trimmed oscillator for precise duty cycle control, a temperature compensated reference, high gain error amplifier, current sensing comparator, and a high current totempole output ideally suited for driving a power MOSFET. Protection circuitry includes built undervoltage lockout and current limiting. The 3842 and 3844 have UVLO thresholds of 16 V (on) and 10 V (off). The corresponding thresholds for the 3843/
45 are 8.4V (on) and 7.6V (off). The 3842) and 3843 can operate within 100% duty cycle. The 3844 and 3845 can operate within 50% duty cycle.
The 384X has Start-Up Current 0.5mA (typ).
Features
• Low Start-Up and Operating Current
• High Current Totem Pole Output
• Undervoltage Lockout With Hysteresis
• Operating Frequency Up To 500KHz
Pin Connection
Top view
Block diagram
(toggle flip flop used only in 3844, 3845)
Absolute Maximum Ratings
Symbol | Parameter | Maximum | Units | |
VCC | Supply Voltage (low impedance source) | 30 | V | |
IO | Output Current | ±1 | A | |
VI | Input Voltage (Analog Inputs pins 2,3) | ![]() | -0.3 to 5.5 | V |
ISINK (E.A) | Error Amp Output Sink Current | 10 | mA | |
Po | Power Dissipation (TA=250C) | 1 | W | |
Tstg | Storage Temperature Range | -65 to150 | oC | |
TL | Lead Temperature (soldering 5 sec.) | 260 | oC | |
TA | Operating Ambient Temperature | 0 to 70 | oC |
www.umw-ic.com 1 友台半导体有限公司
UMW R UMW UC3842/43/44/45
Electrical characteristics
(*VCC=15V, RT=10kΩ, CT=3.3nF, TA=0℃to +70℃, unless otherwise specified)
Characteristics | Symbol | Test Conditions | Min | Typ | Max | Units | ||
Reference Section | ||||||||
Reference Output Voltage | VREF | TJ = 25°C, IREF = 1 mA | 4.9 | 5.0 | 5.1 | V | ||
Line Regulation | ∆VREF | 12V ≤ VCC ≤ 25 V | 6.0 | 20 | mV![]() | |||
Load Regulation | ∆VREF | 1 mA ≤ IREF ≤ 20mA | 6.0 | 25 | ||||
Short Circuit Output Current | ISC | TA = 25°C | -100 | -180 | mA | |||
Oscillator Section | ||||||||
Oscillation Frequency | f | TJ = 25°C | 384X | 47 | 50 | 57 | KHz - | |
384X | 47 | 52 | 57 | |||||
Frequency Change with Voltage | ∆f/∆VCC | 12V ≤ VCC ≤ 25 V | 0.05 | 1.0 | % | |||
Oscillator Amplitude | V(OSC) | (peak to peak) | 1.6 | V | ||||
Error Amplifier Section | ||||||||
Input Bias Current | IBIAS | VFB=3V | -0.1 | -2 | µA | |||
Input Voltage | VI(E.A) | Vpin1 = 2.5V | 2.42 | 2.5 | 2.58 | V | ||
Open Loop Voltage Gain | AVOL | 2V ≤ V0 ≤ 4V | 65 | 90 | dB - | |||
Power Supply Rejection Ratio | PSRR | 12V ≤ VCC ≤ 25 V | 60 | 70 | ||||
Output Sink Current | ISINK | Vpin2 = 2.7V, Vpin1 = 1.1V | 2 | 7 | mA | |||
Output Source Current | ISOURCE | Vpin2 = 2.3V, Vpin1 = 5V | -0.5 | -1.0 | mA | |||
High Output Voltage | VOH | Vpin2 = 2.3V, RL = 15KΩ to GND | 5.0 | 6.0 | V - | |||
Low Output Voltage | VOL | Vpin2 = 2.7V, RL = 15KΩ to PIN 8 | 0.8 | 1.1 | ||||
Current Sense Section | ||||||||
Gain | GV | (Note 1 & 2) | 2.85 | 3.0 | 3.15 | V/V | ||
Maximum Input Signal | VI(MAX) | V pin1 = 5V (Note1) | 0.9 | 1.0 | 1.1 | V | ||
Supply Voltage Rejection | SVR | 12V ≤ VCC ≤ 25 V (Note 1) | 70 | dB | ||||
Input Bias Current | IBIAS | Vpin3 = 3V | -3.0 | -10 | µA | |||
Output Section | ||||||||
Low Output Voltage | VOL | ISINK = 20 mA | 0.08 | 0.4 | V | ![]() ![]() ![]() | ||
ISINK = 200 mA | 1.4 | 2.2 | ||||||
High Output Voltage | VOH | ISINK = 20 mA | 13 | 13.5 | ||||
ISINK = 200 mA | 12 | 13.0 | ||||||
Rise Time | tR | TJ = 25°C, CL = 1nF (Note 3) | 45 | 150 | nS - | |||
Fall Time | tF | TJ = 25°C, CL = 1nF (Note 3) | 35 | 150 | ||||
Undervoltage Lockout Section | ||||||||
Start Theshold | VTH(ST) | 3842/44 | 14.5 | 16.0 | 17.5 | V - | ||
3843/45 | 7.8 | 8.4 | 9.0 | |||||
Min. Operating Voltage (After Turn On) | VOPR(min) | 3842/44 | 8.5 | 10 | 11.5 | V - | ||
3843/45 | 7.0 | 7.6 | 8.2 | |||||
PWM Section | ||||||||
Max. Duty Cycle | D(MAX) | 3842/43 | 95 | 97 | 100 | ![]() ![]() | ||
3844/45 | 47 | 48 | 50 | |||||
Min. Duty Cycle | D(MAX) | 0 | ||||||
Total Standby Current | ||||||||
Start-Up Current | IST | 384X | 0.05 | mA - | ||||
Operating Supply Current | ICC (OPR) | Vpin3 = Vpin2 = 0V | 13 | 17 | ||||
Zener Voltage | VZ | ICC=25 mA | 30 | 38 | V |
* - Adjust VCC above the start threshold before setting it to 15V.
Note 1: Parameter measured at trip point of latch with Vpin2=0.
Note 2: Gain defined as A=∆Vpin1/∆Vpin3 ; 0 ≤ Vpin3 ≤ 0.8V.
Note 3: These parameters, although guaranteed, are not 100% tested in production.
UMW
UMW UC3842/43/44/45
Pinfunctions
N | Function | Description |
---|---|---|
1 | COMP | This pin is the Error Amplifier output and is made for loop compensation. |
2 | VFB | This is the inverting input of the Error Amplifier. It is normally connected to the switching power supply output through a resistor divider. |
3 | ISENSE | A voltage proportional to inductor current is connected to this input. The PWM uses this information to terminate the output switch conduction. |
4 | RT/CT | The oscillator frequency and maximum Output duty cycle are programmed by connecting resistor RT to Vref and capacitor CT to ground. |
5 | GROUND | This pin is the combined control circuitry and power ground. |
6 | OUTPUT | This output directly drives the gate of a power MOSFET. Peak currents up to 1A are sourced and sink by this pin. |
7 | VCC | This pin is the positive supply of the integrated circuit. |
8 | Vref | This is the reference output. It provides charging current for capacitor CT through resistor RT . |
